1.480,00 ден.
24 рати x 66,00 ден.
- 747069575
- 24 месеци
- Мрежа, алати, кабли и адаптери
G1105PD
5-Port Gigabit PD Switch With 4-Port PoE
G2224D is a 24-port Gigabit intelligent cloud management switch independently designed by IP-COM. It supports cloud WEB platform management and Profi APP management. It can automatically detect loops and private routers and send alarms. Network maintenance is more efficient, after-sales costs are lower, and switches can be configured without leaving home.
• Five 10/100/1000 Mbps auto-negotiation ports
• Port 5 supports power supply by a PSE compliant with IEEE 802.3af/at
• Ports 1 - 4 support power supply to low-power PDs compliant with IEEE 802.3af
• The switch supports auto MDI/MDIX, simplifing the network structure and maintenance
• The non-blocking wire-speed forwarding function guarantees the smooth operation of network applications
• Full-duplex flow control and half-duplex back pressure control prevent frame loss caused by port blocking
• The switch supports the store-and-forward transfer mode and a 2 K MAC address table
• The switch supports 9K jumbo frame, improving the forwarding rate of large files
• The switch supports IP camera connection and guarantees the smoothness and clearness of monitoring videos
Specification
Hardware specifications
Network standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Transmission media: 10Base-T: CAT3 UTP or better; 100Base-TX: CAT5 UTP or better; 1000Base-T: CAT5e UTP or better
Dimensions: 100 mm x 100 mm x 26 mm(L x W x H)
Product material: Metal
Fan: Fanless
LED indicators: 1 x Power LED indicator; 4 x PoE LED indicator; 5 x Link/Act LED indicator
Service port description
Fixed ports: 5 x 10/100/1000 Mbps auto-negotiation RJ45 ports (supporting Auto MDI/MDIX)
PoE out: PoE standard:IEEE 802.3af; PoE power cable core:8 cores: voltage of cores 1, 2, 4, 5 is +, and cores 3, 6, 7, 8 is -; PoE port:1 - 4; Maximum output power of a single port:15.4 W; Maximum output power of the switch:22 W
PoE in: PoE in standard:IEEE802.3af, IEEE802.3at; PoE in port:5; PoE input:50 - 57V DC, 0.6A
Protection: Port lightning protection: 6 kV; Power lightning protection: No; Electrostatic protection:; - Air discharge: ±8 kV; - Contact discharge: ±6 kV
Performance
Forwarding mode: Store-and-forward
Switching capacity: 10 Gbps
Packet forwarding rate: 10 Mbps: 14880 pps; 100 Mbps: 148800 pps; 1000 Mbps: 1488000 pps
Buffer: 1 Mb
MAC address table: 2 K
Jumbo frame: 9 K
Installation method: Desktop mounting: Support; Wall mounting: Not support; Rack mounting: Not support
Environment: Operating temperature: 0°C - 45°C; Storage temperature: -40°C - 70°C; Operating humidity: (10% - 90%), non-condensing; Storage humidity: (5% - 90%), non-condensing
Certificates: CQC, FCC, CE, RoHS
Software specifications
Protocol: CDMA/CD
MAC address learning: Auto-learning, auto-updating
Function: No
