6.980,00 ден.
24 рати x 308,00 ден.
- 747067714
- 24 месеци
- Мрежа, алати, кабли и адаптери
• 4-Channel Live View and 4K HDMI Video Output
• 4× 10/100 Mbps PoE+ Ports with 53 W PoE Budget△
• Up to 2-ch @ 8MP (25fps) / 4-ch @ 4MP (30fps) Decoding Capability
• 4-Channel Synchronous Playback†
• 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
• 1× SATA Interface and 1 Up to 10 TB*
• H.265+ Compression Technology
• HDMI and VGA Simultaneous Output
• Remote Monitoring
Video and Audio
IP Video Input: 4-Channel
Incoming Bandwidth: 80 Mbps
Outgoing Bandwidth: 60 Mbps
HDMI Output Resolution: 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output Resolution: 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode: HDMI/VGA Simultaneous Output
Multi-View Display: 1/4
DECODING
Audio Compression: G.711A/G.711U/G.726
Video Compression: H.265+/H.265/ H.264+/H.264
Record Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
Synchronous Playback: 4-Channel†
Capability:
• 25fps:
2-ch @ 8MP, 4-ch @ 4MP
• 30fps:
4-ch @ 4MP, 3-ch @ 5MP
Record Management
Record Mode:
• Manual Recording
• Scheduling Recording
• Motion Detection Recording
Playback Mode:
• Instant Playback
• Regular Playback
• Tag Playback
• Event Playback
Backup Mode:
• Regular Backup
• Video Clip Backup
Playback Function:
• Play
• Pause
• Stop
• Fast Forward
• Fast Backward
• Play By Frame
• Full Screen
• Video Clip
• Export Clip
• Digital Zoom
• Lock Recording
• Audio On/Off
NETWORK
Protocol: UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Mobile Phone Access: Android, iOS
Web Browser: Chrome (57+), Firefox (52+), Edge (91+)
Interoperability: ONVIF Profile S/T, CGI
External Interface
Network Interface: 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
USB Interface: 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port
Audio Interface: 1-ch RCA Input; 1-ch RCA Output
Alarm In/Out: N/A
Serial Interface: N/A
Power: 1× DC Jack
Reset Button: 1
Speaker: N/A
eSATA: N/A
HDMI: 1
VGA: 1
HARD DISK
SATA: 1 SATA Interface
Capacity:
• Up to 10 TB Capacity for Each HDD
• 1 × 2TB HDD Preinstalled
PoE
Standard: 802.3at/af Compliant
Interface: 1- 4, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
PoE Budget: 53 W△ Available for All PoE+ Ports, 30 W Max per Port
Alarm
General Alarm:
• Motion Detection
• Video Tampering
• Scene Change Detection
• Line-Crossing Detection
• Intrusion Detection
• Region Entering Detection
• Region Exiting Detection
• Loitering Detection
• Object Abandoned/Removal Detection
• Vehicle Detection
• Human Detection
• Abnormal Sound Detection
• Smart Frame
Note: The alarm function requires the use of a camera.
Anomaly Alarm:
• Video Loss
• Offline and IP Conflict
• Disk Exception
• Login Exception
Alarm Linkage:
• Recording
• White Light Alarm
• Buzzer
• Log
• Audible Alarm
Note: The alarm function requires the use of a camera.
GENERAL
Storage Temperature: -40 ℃ to 70 °C (-40 ℉ to 158 ℉)
Storage Humidity: 10%~90% RH Non-Condensing
Package Content:
• VIGI Network Video Recorder
• Power Adapter
• HDD Screws
• Rubber Feet
• Mouse
• Quick Installation Guide
Working Temperature:
• NVR: -10 ℃ to 55 °C (14 ℉ to 131 ℉）
• Power Adapter: 0 ℃ to 40 °C (32 ℉ to 104 ℉)
Working Humidity: 10%~90% RH Non-Condensing
Dimensions( W X D X H ): 9.7 × 5.8 × 1.8 in (246.2 × 148.2 × 45 mm)
Power Supply: 53.5V DC/1.31A
Max. Power Consumption:
• 4.25 W (Without Disk)
• 13.10 W (With Disk)
Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
