• Deco uses a system of units to achieve seamless whole-home Wi-Fi coverage — eliminate weak signal areas once and for all.
• With advanced Deco Mesh Technology, units work together to form a unified network with a single network name. Devices automatically switch between Decos as you move through your home for the fastest possible speeds.
• A Deco E4 three-pack delivers Wi-Fi to an area of up to 4,000 square feet (EU version). And if that’s not enough, simply add more Decos to the network anytime to increase coverage.
• Deco E4 provides fast and stable connections with speeds of up to 1167 Mbps and works with the major internet service provider (ISP) and modem.
• Deco can handle traffic from even the busiest of networks, providing lag-free connections for up to 100 devices.
• Parental Controls limits online time and block inappropriate websites according to unique profiles created for each family member.
• Setup is easier than ever with the Deco app there to walk you through every step.
Specifications
WIRELESS
Standards and Protocols: Wi-Fi 5
• IEEE 802.11ac/n/a 5 GHz
• IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds: AC1200
• 5 GHz: 867 Mbps (802.11ac)
• 2.4 GHz: 300 Mbps (802.11n)
WiFi Range: 3-4 Bedroom Houses (3-pack)
• TP-Link Mesh Technology
• Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• 2× Antennas (Internal)
• Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity: Medium
• Dual-Band
• Distribute devices to different bands for optimal performance
MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients
Working Modes: Router Mode; Access Point Mode
SECURITY
Network Security: SPI Firewall; Access Control
Guest Network:
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
WiFi Encryption: WPA-Personal; WPA2-Personal
HARDWARE
Ethernet Ports: 2× 10/100 Mbps Ports; *Per Deco Unit
Buttons: Reset Button
SOFTWARE
Protocols: IPv4; IPv6
Parental Controls: URL Filtering; Time Controls
WAN Types: Dynamic IP; Static IP; PPPoE; PPTP; L2TP
Quality of Service: QoS by Device
Cloud Service: OTA Firmware Upgrade; TP-Link ID; DDNS
NAT Forwarding: Port Forwarding; UPnP
IPTV: IGMP Proxy; IGMP Snooping; Bridge; Tag VLAN
DHCP: Address Reservation; DHCP Client List; Server
DDNS: TP-Link
Management Features: Deco App
OTHER
Network Services Enabled by Default:
Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DNS
DNS
• Port: 53 Protocol: TCP & UDP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 22 Protocol: TCP
• Port: 20001 Protocol: TCP
• Port: 30001 Protocol: TCP
• Port: 20002 Protocol: UDP
TEST DATA
WiFi Transmission Power:
CE:
• <20 dBm (2.4 GHz)
• <23 dBm (5 GHz)
FCC:
• <30 dBm
PHYSICAL
Dimensions (W×D×H): 3.6 × 3.6 × 7.5 in (90.7 × 90.7 × 190 mm)
Package Content:
• Deco E4 (3-pack)
• 3 Deco E4 Units
• 1 RJ45 Ethernet Cable
• 3 Power Adapters
• Quick Installation Guide
OTHERS
System Requirements: Android 5.0 or later, iOS 9.0 or later
*Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information.
Certifications: CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
Environment:
• Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
