• Unrivalled Wi-Fi 6 Speed—Breaks the gigabit barrier with speed up to 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
• Smoother Experience— lower latency ensures ultra-responsive gaming, uninterrupted video chatting, and seamless live streaming
• Wider Signal Coverage— Connect to your Wi-Fi in more parts of your home with two external high-gain antennas ensuring greater coverage and enhanced stability
• Bluetooth 5.3—The latest Bluetooth technology achieves Faster Speed and Broader Coverage than the previous version
• Improved Security—The latest security enhancements WPA3 provides enhanced protection in personal password safety
• Fine Crafting—Specialized gold plating is crafted to improve stability and reliability even in hot environments
• Backward Compatibility – Full support for 802.11ac/a/b/g/n standards
Specifications
HARDWARE FEATURES
Dimensions ( W x D x H ): 3.09 × 4.76 × 0.85 in (78.5 × 120.8 × 21.5 mm)
Antenna: Two High-Gain Dual Band Antennas
Bluetooth Features
Standards and Protocols: Bluetooth 5.3,Bluetooth 5.2, Bluetooth 5.0, Bluetooth 4.2, Bluetooth 4.0
Interface: F_USB 2.0
WIRELESS FEATURES
Wireless Standards:
• IEEE 802.11ax/ac/n/a 5 GHz
• IEEE 802.11ax/n/g/b 2.4 GHz
• Bluetooth 5.3/5.2/5.0/4.2/4.0
WLAN Signal Rate:
5 GHz:
• 11ax: Up to 2402 Mbps(dynamic)
• 11ac: Up to 1733 Mbps(dynamic)
• 11n: Up to 300 Mbps(dynamic)
• 11a: Up to 54 Mbps(dynamic)
2.4 GHz:
• 11ax: Up to 574 Mbps(dynamic)
• 11n: Up to 300 Mbps(dynamic)
• 11g: Up to 54 Mbps(dynamic)
• 11b: Up to 11 Mbps(dynamic)
WLAN Reception Sensitivity:
5 GHz:
• 11ax HT160:-56.25dBm
• 11ax HT80: -59dBm
• 11ax HT40: -62.25dBm
• 11ax HT20: -65dBm
• 11ac HT160:-62dBm
• 11ac HT80: -65.5dBm
• 11ac HT40: -69.75dBm
• 11ac HT20: -73.75dBm
• 11n HT40: -74.5dBm
• 11n HT20: -77.5dBm
• 11a 54Mbps: -77.75dBm
• 11a 6Mbps: -94.5dBm
2.4GHz:
• 11ax HT40: -60.75dBm
• 11ax HT20: -63.75dBm
• 11n HT40: -73dBm
• 11n HT20: -76.25dBm
• 11g 54Mbps: -76.5dBm
• 11b 11Mbps: -89dBm
WLAN Transmit Power: 5 GHz: 28dBm(FCC) / 23dBm(CE) (EIRP); 2.4 GHz: 24dBm(FCC) / 20dBm(CE) (EIRP)
WLAN Modes: Client mode, Hotspot mode
Wireless Security: WEP, WPA/WPA2/WPA3(Personal/Enterprise), WPA-PSK/WPA2-PSK
Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM, 1024QAM
OTHERS
Certification: CE, FCC, RoHS
Package Content:
• Archer TX55E
• Two High-Gain Antennas
• Low-Profile Bracket
• Standard Bluetooth Header Cable
• Quick Installation Guide
• Resource CD
System Requirements: Windows 11/10(64-bit) only
Environment:
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
