CPU Specifications
Total Cores: 18
# of Performance-cores: 6
# of Efficient-cores: 12
# of Low Power Efficient-cores: 0
Total Threads: 18
Max Turbo Frequency: 5.3 GHz
Performance-core Max Turbo Frequency: 5.3 GHz
Efficient-core Max Turbo Frequency: 4.6 GHz
Performance-core Base Frequency: 4.2 GHz
Efficient-core Base Frequency: 3.3 GHz
Cache: 30 MB Intel® Smart Cache
Total L2 Cache: 30 MB
Processor Base Power: 125 W
Maximum Turbo Power: 159 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
AI Software Frameworks Supported by CPU: OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN
CPU Lithography: TSMC N3B
Memory Specifications
Max Memory Size (dependent on memory type): 256 GB
Memory Types: Up To DDR5 7200 MT/s
Max # of Memory Channels: 2
ECC Memory Supported : Yes
GPU Specifications
GPU Name: Intel® Graphics
Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.9 GHz
GPU Peak TOPS (Int8): 8
Graphics Output: eDP1.4b | DP 2.1 UHBR20 | HDMI 2.1 FRL
Xe-cores: 4
Max Resolution (HDMI): 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)7680 x 4320 @ 60Hz (HDMI 2.1 FRL)
Max Resolution (DP): 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel): 3840 x 2400 @ 120Hz
DirectX* Support: 12
OpenGL* Support: 4.5
OpenCL* Support: 3
H.264 Hardware Encode/Decode: Yes
H.265 (HEVC) Hardware Encode/Decode: Yes
AV1 Encode/Decode: Yes
Intel® Quick Sync Video: Yes
# of Displays Supported : 4
Device ID: 0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes
AI Software Frameworks Supported by GPU: OpenVINO™ | WindowsML | DirectML | ONNX RT | WebGPU
NPU Specifications
NPU Name: Intel® AI Boost
NPU Peak TOPS (Int8): 13
Sparsity Support: Yes
Windows Studio Effects Support: Yes
AI Software Frameworks Supported by NPU: OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN
Expansion Options
Direct Media Interface (DMI) Revision: 4
Max # of DMI Lanes: 8
Intel® Thunderbolt™ 4: Yes
Scalability: 1S Only
PCI Express Revision: 5.0 and 4.0
PCI Express Configurations : Up to 1x16+2x4 | 2x8+2x4 | 1x8+4x4
Max # of PCI Express Lanes: 24
Package Specifications
Sockets Supported: FCLGA1851
Thermal Solution Specification: PCG 2020A
Max Operating Temperature: 105 °C
Package Size: 45 mm x 37.5 mm
