G2220P-16-250W
18GE+2SFP Cloud Managed PoE Switch
G2220P-16-250W is a 20-port intelligent cloud-managed PoE switch independently designed by IP-COM. Supports cloud WEB platform management and APP management, supports 802.3AF/AT, single port maximum output 30W, whole machine 250W, automatically detects loops and private routers at the same time, network maintenance is more efficient, and after-sales costs are affordable. User-configured switch, supports watchdog, 7*24 hours automatic operation and maintenance, and is
an ideal choice for accessing PD devices such as APs, cameras, and IP phones.
• Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3x, IEEE802.3z, IEEE802.1p, IEEE802.1q standards
• 18 10/100/1000 Base-T Ethernet ports, 2 1000 Base-X SFP optical ports
• 8 K MAC address table and MAC address auto learning
• 16 PoE ports, single port output power 30W, Total power budget 230W
• 40Gbps non-blocking wire-speed forwarding
• Web platform remote management, mobile APP management
• 4M large cache
• Support QVLAN, DHCP Snooping, anti-loop, PoE timing, watchdog, etc.
Specification
Hardware
Dimensions: 440mm*178mm*44mm
Mounting: Rack mounting: support; Desktop mounting: support; Wall mounting: support
Enclosure material: Metal
Interfaces: (18)1GE RJ45 ports; (2)1GE SFP ports
PoE interface: (16) PoE (Pins 1, 2+; 3, 6-)
LED Indicator: Power; Link/Act; PoE MAX
Switching capacity: 40Gbps
Forwarding rate: 29.8Mpps
Power method: 100-240V AC，50 / 60Hz
Power consumption: 250W
Total available PoE: 230W
Total available PoE: 30W
Lightning protection: Port: 6 KV; Power：6 KV
Button: Funtion mode Button
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: 10% - 90%,non-condensing
Storage humidity: 5% - 90%,non-condensing
Certifications: FCC, CE, RoHS
Software
PoE Management: Support dynamic display of PoE consumption power and PoE remaining power; Support PoE ports on and off
Security features: Support whitelist binding of MAC addresses, ports and VLAN; Support port isolation
VLAN: Support VLAN transparent transmission; Support IEEE 802.1q VLAN
DHCP Server: Support DHCP Client
STP: Support loop guard on each port
Port mirroring: Support N: 1 port mirroring
QoS: Support storm control on ports; Support ingress and egress rate limits on ports; Support port flow control
Cloud Management: Support configuration delivery from ProFi Cloud management platform; Support ProFi App management; Support log reporting and fault detection; Support remote maintenance: reboot, backup, upgrade
Loading and upgrade: Support HTTP upgrade; Support Configuration import and export
Management and maintenance: Support web management and maintenance; Support Ping and Tracert tests; Support VCT
