G2226F
24GE+2SFP Cloud Managed Switch
G2220P-16-250W is a 20-port intelligent cloud-managed PoE switch independently designed by IP-COM. Supports cloud WEB platform management and APP management, supports 802.3AF/AT, single port maximum output 30W, whole machine 250W, automatically detects loops and private routers at the same time, network maintenance is more efficient, and after-sales costs are affordable. User-configured switch, supports watchdog, 7*24 hours automatic operation and maintenance, and is an ideal choice for accessing PD devices such as APs, cameras, and IP phones.
• Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3z, IEEE802.1p, IEEE802.1q standards
• 24 × GE+2× SFP
• 8 K MAC address table and MAC address auto learning
• IEEE 802.3x full-duplex flow control and half-duplex backpressure flow control
• Cloud web UI and ProFi
• 52 Gbps switching fabric for non-blocking line-speed forwarding App management
• Support QVLAN, DHCP Snooping, loop protection, etc.
Specification
Hardware
Dimensions: 440mm*178mm*44mm
Mounting: Desktop mounting: support; Wall mounting: support; Rack mounting : support
Enclosure material: Metal
Interfaces: (24)1GE RJ45 ports; (2)1GE SFP ports
LED Indicator: Power; Link/Act; System
Switching capacity: 52Gbps
Forwarding rate: 38.7Mpps
Power method: 100-240V AC,50 / 60Hz
Power consumption: Max:<12W
Lightning protection: Port: 6 KV; Power:6 KV
Button: Factory reset
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: 10% - 90%,non-condensing
Storage humidity: 5% - 90%,non-condensing
Certifications: FCC, CE, RoHS
Software
Security features: Support whitelist binding of MAC addresses, ports and VLAN; Support port isolation
VLAN: Support VLAN transparent transmission; Support IEEE 802.1q VLAN
DHCP Server: Support DHCP Client; Support DHCP Snooping
STP: Support loop guard on each port
Port mirroring: Support N: 1 port mirroring
QoS: Support DSCP priority; Support SP, SWP, WP
Cloud Management: Support configuration delivery from Cloud management platform; Support ProFi App management; Support log reporting and fault detection; Support remote maintenance: reboot, backup, upgrade
Loading and upgrade: Support HTTP upgrade; Support configuration import and export
Management and maintenance: Support ProFi App management; Support Cloud web UI management; Support local web UI management; Support ping test
