G2228P-24-410W
26GE+2SFP Cloud Managed PoE Switch
G2228P-24-410W is a 28-port PoE switch supporting IP-COM ProFi web and app management. Compatible with 802.3af/at standards, this switch provides up to 30W per port and up to 410W as a whole. It also supports detection of loops and unauthorized access, and 24/7 watchdog, making it an ideal choice for adding PD devices such as APs, cameras, and IP phones to your network and reducing time and costs on maintenance.
Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3x, IEEE802.3z, IEEE802.1p, IEEE802.1q standards
26 10/100/1000 Base-T Ethernet ports, 2 1000 Base-X SFP optical ports
8 K MAC address table and MAC address auto learning
24 PoE ports, single port output power 30W, Total power budget 370W
56Gbps non-blocking wire-speed forwarding
Web platform remote management, mobile APP management
4M large cache
Support QVLAN, DHCP Snooping, anti-loop, PoE timing, watchdog, etc
Specification
Dimensions: 440mm*240mm*44mm
Mounting: Rack mounting: support; Desktop mounting: support; Wall mounting: support
Enclosure material: Metal
Interfaces: (26)1GE RJ45 ports; (2)1GE SFP ports
PoE interface: (24) PoE(Pins 1, 2+; 3, 6-)
LED Indicator: Power; Link/Act; PoE MAX
Switching capacity: 56Gbps
Forwarding rate: 41.7Mpps
Power method: 100-240V AC,50 / 60Hz
Power consumption: 410W
Total available PoE: 370W
Total available PoE: 30W
Lightning protection: Port: 6 KV Power:6 KV
Button: Funtion mode Button
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: 10% - 90%,non-condensing
Storage humidity: 5% - 90%,non-condensing
Certifications: FCC, CE, RoHS
Software
PoE Management: Support dynamic display of PoE consumption power and PoE remaining power; Support PoE ports on and off
Security features: Support whitelist binding of MAC addresses, ports and VLAN; Support port isolation
VLAN: Support VLAN transparent transmission; Support IEEE 802.1q VLAN
DHCP Server: Support DHCP Client
STP: Support loop guard on each port
Port mirroring: Support N: 1 port mirroring
QoS: Support storm control on ports; Support ingress and egress rate limits on ports; Support port flow control
Cloud Management: Support configuration delivery from ProFi Cloud management platform; Support ProFi App management; Support log reporting and fault detection; Support remote maintenance: reboot, backup, upgrade
Loading and upgrade: Support HTTP upgrade; Support Configuration import and export
Management and maintenance: Support web management and maintenance; Support Ping and Tracert tests; Support VCT
