4.980,00 ден.
24 рати x 220,00 ден.
- 747066238
- 24 месеци
- Home, Business & Outdoor
• 3MP Super-High Definition and 24h Full-Color
• Human & Vehicle Classification
• Smart Detection
• Smart Video Enhancement Technology
• Built-In Microphone
• H.265+ Compression Technology
• Remote Management
Specifications
CAMERA
Image Sensor: 1/2.8” Progressive Scan CMOS
Shutter Speed: 1/3 to 1/10000 s
Slow Shutter: Yes
Minimum Illumination: 0.005 Lux; 0 Lux with IR/White Light
Day/Night Mechanism: IR Cut Filter
Day/Night Switch: Unified/ Scheduled/ Auto
LENS
Type: Fixed Focal Lens
Focal Length: 2.8/4 mm
Aperture: 2.8 mm: F1.6
FOV: Horizontal FOV: 107.5°, Vertical FOV: 57.2°, Diagonal FOV: 128.7°
Lens Mount: M12
DORI Distance:
Detect: 52 m (170 ft)
Observe: 22 m (71 ft)
Recognize: 10 m (34 ft)
Identify: 5 m (17 ft)
Angle Adjustment (Manual)
Range:
• Pan: 0° to 360°
• Tilt: 0° to 85°
• Rotate: 0° to 360°
ILLUMINATOR
IR LED:
• Quantity: 2
• Range: 30m
• Wavelength: 850nm
White LED:
• Quantity: 2
• Range: 30m
Illuminator On/Off Control: Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution: 2304 × 1296
Main Stream:
• Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720
Sub-Stream:
• Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• Resolution: 704x576, 640x480, 352x288, 320x240
Bit Rate Control: CBR, VBR
Video Compression:
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
H.264 Type: High Profile
H.264+: Main Stream Supported
H.265 Type: Main Profile
H.265+: Main Stream Supported
Video Bit Rate: • Main Stream: 256 Kbps to 4 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps
Image Settings:
• Mirror
• Brightness
• Contrast
• Saturation
• Sharpness
• Exposure
• WDR
• White Balance
• Prevent Overexposure to Infrared Light
• HLC Adjustable by Client Software
• Rotation(90°/270°)
Image Enhancement: BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range: WDR
SNR: ≥ 52 dB
Image Parameters Switch: Yes
Privacy Mask: Up to 4 Masks
ROI: 1 Region
OSD Setting: Yes
AUDIO
Audio Communication: N/A
Audio Input: Yes (Built-in Microphone)
Audio Output: N/A
Audio Compression: Yes
Audio Sampling Rate: 8KHz
Environment Noise Filtering: Yes
Audio Bit Rate: 64 Kbps(G.711 alaw)
NETWORK
Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
ONVIF: Yes
API: Open Network Video Interface (Profile S/T)
Simultaneous Live View: 3 Main Streams & 3 Sub-Streams
Client: VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
Web Browser:
• Google Chrome® 57 and above
• Firefox® 52 and above
• Safari® 11 and above
• Microsoft® Edge 91 and above
Cloud: Yes
Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
ALARM AND EVENT MANAGEMENT
Smart Event:
• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Object Abandoned/Removal Detection
• Abnormal Sound Detection
• People Detection
• Vehicle Detection
Basic Event:
• Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
• Video Tampering Detection
• Exception ( Illegal Login)
Alarm Linkage:
• White Light Flashing
• Message Push
INTERFACES
Network Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm: N/A
Reset Button: N/A
Power: DC Power Port
On-board Storage: N/A
Built-in Microphone: Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker: N/A
Audio: N/A
GENERAL
Package Content:
• VIGI Network Camera
• Quick Start Guide
• Mounting Accessories
Material: Plastic
Net Weight: 0.21 Kg
Power Supply:
• 12V DC ± 5%, Max. 5.5 W, 5.5mm Coaxial Power Plug
• PoE: 802.3af/at, class 0. Max. 6 W
Product Dimensions (L x W x H): 4.8 × 3.3 × 4.8 in (123 × 83 × 123 mm)
