• 8× 10/100Mbps Auto-Negotiation RJ45 port, supporting Auto-MDI/MDIX
• Green Ethernet technology saves power
• IEEE 802.3X flow control provides reliable data transfer
• Plastic casing and desktop design
• Plug and play, no configuration needed
• Fanless design ensures quiet operation
Specifications
HARDWARE FEATURES
Interface: 8× 10/100Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports
Fan Quantity: Fanless
External Power Supply: External Power Adapter (Output: 5VDC / 0.6A)
Dimensions ( W x D x H ): 4.9 × 1.9 × 0.9 in. (124.6 × 48.7 × 22.8 mm)
Max. Power Consumption: 2.64W
Max Heat Dissipation: 9.002 Btu/hr
SOFTWARE FEATURES
Advanced Features: Green Technology
802.3X Flow Control
Back Pressure
Transmission Method: Store and Forward
OTHERS
Certification: CE, RoHS
Package Content:
• 8-Port 10/100Mbps Desktop Switch
• Power Adapter
• Installation Guide
Environment:
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40℃~60℃ (-40℉~140℉)
• Operating Humidity: 10% ~ 90% non-condensing
• Storage Humidity: 5%~90% non-condensing
