• Gigabit WiFi for 8K Streaming – 5400 Mbps WiFi for faster browsing, streamings, and downloading, all at the same time.†
• Fully Featured Wi-Fi 6 – Equips with the top structure of 4T4R and HE160 on the 5 GHz band to enable 4.8 Gbps ultra-fast connection.
• Connect 200+ Devices§ – Supports MU-MIMO and OFDMA to reduce congestion and quadruple the average throughput.‡**
• Extensive Coverage – 6× antennas and Beamforming ensure broad coverage.
• HomeShield – TP-Link's premium security services keep your home network safe with cutting-edge features for network and IoT protection.*
• More Vents, Less Heat – Improved vents area unleash the full power of the whole machine.
• USB Sharing – 1× USB 3.0 port enables easy media sharing and private cloud building.
• Easy Setup – Set up the router in minutes with Tether app.
• Link Aggregation – Static Link Aggregation (LAG) available with 2× LAN ports
Specifications
WIRELESS
Standards and Protocols:
Wi-Fi 6:
• IEEE 802.11ax/ac/n/a 5 GHz
• IEEE 802.11ax/n/b/g 2.4 GHz
WiFi Speeds: AX5400
• 5 GHz: 4804 Mbps (802.11ax, HE160)
• 2.4 GHz: 574 Mbps (802.11ax)
WiFi Range:
3 Bedroom Houses:
• 6× Fixed High-Performance Antennas
• Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM: Improves transmission power to strengthen signal coverage
4T4R: Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity:
High:
• Dual-Band
• Allocate devices to different bands for optimal performance
4×4 MU-MIMO: Simultaneously communicates with multiple MU-MIMO clients
OFDMA: Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness: Improves network efficiency by limiting excessive occupation
DFS: Access an extra band to reduce congestion
6 Streams: Connect your devices to more bandwidth
Working Modes: Router Mode; Access Point Mode
SECURITY
Network Security: SPI Firewall; Access Control; IP & MAC Binding; Application Layer Gateway
Guest Network:
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
VPN Server:
• OpenVPN
• PPTP
• L2TP
VPN Client:
• OpenVPN
• PPTP
• L2TP
WiFi Encryption: WPA; WPA2; WPA3; WPA/WPA2-Enterprise (802.1x)
HARDWARE
Processor: 1.5 GHz Triple-Core CPU
Ethernet Ports:
• 1× Gigabit WAN Port
• 4× Gigabit LAN Ports
• Static Link Aggregation (LAG) available with 2× LAN ports
USB Support:
• 1× USB 3.0 Port
Supported Partition Formats: NTFS, exFAT, HFS+, FAT32
Supported Functions: Apple Time Machine; FTP Server; Media Server; Samba Server
Buttons: Wi-Fi On/Off Button; Power On/Off Button; LED On/Off Button; WPS Button; Reset Button
Power: 12 V ⎓ 2 A
SOFTWARE
Protocols: IPv4; IPv6
Service Kits: HomeShield
OneMesh™: OneMesh™ Supported
Parental Controls HomeShield: Parental Controls; Custom Profiles; Professional Content Filter Library; Family Time; Bedtime; Off Time; Time Rewards; Family Online Time Ranking; Pause the Internet; Weekly and Monthly Reports
WAN Types: Dynamic IP; Static IP; PPPoE; PPTP; L2TP
Quality of Service: QoS by Device
Cloud Service: Auto Firmware Upgrade; TP-Link ID; DDNS
NAT Forwarding: Port Forwarding; Port Triggering; DMZ; UPnP; Virtual Server
IPTV: IGMP Proxy; IGMP Snooping; Bridge; Tag VLAN
DHCP: Address Reservation; DHCP Client List; Server
DDNS: TP-Link; NO-IP; DynDNS
Management Features: Tether App; Webpage
OTHER
System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
PHYSICAL
Dimensions (W×D×H): 10.7 × 5.8 × 1.9 in (272.5 × 147.2 × 49.2 mm)
Package Content:
• Wi-Fi Router Archer AX73
• Power Adapter
• RJ45 Ethernet Cable
• Quick Installation Guide
