17.480,00 ден.
24 рати x 770,00 ден.
- 747067818
- 24 месеци
- Мрежа, алати, кабли и адаптери
• Tri-Band Six-Stream Outdoor WiFi 7: Up to 9.3 Gbps.
• 6 GHz Band Unlocked by AFC: AFC enables 6 GHz band outdoor uses.
• True Tri-Band Omnidirectional Coverage: 300m2 (3,200ft2) recommended coverage
• Professional Hardware Design: Industry-Leading IP68-Rated, 1× 2.5G PoE+ port, 2.4 GHz dual-polarized antennas.
• Easy and Quick Setup: Wall/pole mounting; Omada SDN for one-click setup
• Advanced Features: Centralized management, mesh, and seamless roaming.
Specifications
HARDWARE FEATURES
Interface: 1× 2.5G Ethernet (RJ-45) Port (Support 802.3at PoE)
Button: Reset
Power Supply: 802.3at PoE
Max. Power Consumption: 21.5W (for PoE)
Dimensions ( W x D x H ): 9.1× 8.2 × 2.8 in (230 × 207.5 × 69.7 mm)
Antenna:
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 6 dBi
• 6 GHz: 2× 6 dBi
GNSS: L1 (1575.42 MHz) receiver, supporting GPS, Galileo, GLONASS, and BeiDou signals
Receive sensitivity: -164dBm (tracking)
GPS antennas: Integrated 3dBi omnidirectional antennas
Bluetooth: BLE 5.2
Weatherproof Enclosure: IP68
Mounting: Pole/Wall Mounting (Kits included)
WIRELESS FEATURES
Coverage: 300m2 (3,200ft2) Recommended Omnidirectional Coverage
Concurrent Clients: 380+**
Wireless Standards: IEEE 802.11be/ax/ac/n/g/b/a
Frequency: 2.4 GHz, 5 GHz, 6 GHz
Signal Rate: 688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz) + 5765 Mbps (6 GHz)†
Wireless Functions:
• 4k-QAM
• OFDMA
• Multiple SSIDs: 24 (8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS (WMM)
• MU-MIMO
• MLO
• 320MHz
• Omada Mesh§
• Seamless Roaming(802.11k/v/r)§
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
• Static IP/Dynamic lP
Wireless Security:
• Captive Portal Authentication§
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Transmission Power:
• CE:
Indoor Mode: < 20 dBm (2.4 GHz, EIRP);, < 23 dBm (5 GHz, band 1 & band 2, ElRP), < 28 dBm (5 GHz, band 3, EIRP); <23dBm (6 GHz, EIRP)
Outdoor Mode: < 20 dBm (2.4 GHz, EIRP); < 28 dBm (5 GHz, band 3, EIRP)
• FCC:
Indoor Mode: < 25 dBm (2.4 GHz); < 25 dBm (5 GHz); < 25 dBm (6 GHz)
Outdoor Mode:< 25 dBm (2.4 GHz); < 25 dBm (5 GHz); < 25 dBm (6 GHz)
Management Features
Omada App: Yes
Centralized Management:
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access: Yes. Require the use of an Omada controller.
Email Alerts: Yes
Management MAC Access Control: Yes
SNMP: v1, v2c
System Logging Local/Remote Syslog: Yes
SSH: Yes
Web-based Management: Yes
L3 Management: Yes
Multi-site Management: Yes
Management VLAN: Yes
Zero-Touch Provisioning: Yes. Requiring the use of Omada Cloud-Based Controller
OTHERS
Certification: CE, FCC, RoHS
Package Content:
• Access Point EAP772-Outdoor
• Waterproof Kit
• Mounting Kits
• Installation Guide
System Requirements: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment:
• Operating Temperature: -30–70 ℃ (-22–158 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing
